Block Ice Making Machine for Fresh-keeping from China Manufacture

Block Ice Making Machine for Fresh-keeping from China Manufacture

  • Block Ice Making Machine for Fresh-keeping from China Manufacture
  • Block Ice Making Machine for Fresh-keeping from China Manufacture
  • Block Ice Making Machine for Fresh-keeping from China Manufacture
  • Block Ice Making Machine for Fresh-keeping from China Manufacture
  • Block Ice Making Machine for Fresh-keeping from China Manufacture
  • Block Ice Making Machine for Fresh-keeping from China Manufacture
Block Ice Making Machine for Fresh-keeping from China Manufacture
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Yixing ICS
Certification: ce
Payment & Shipping Terms:
Minimum Order Quantity: 1 - 2 Sets
Price: $7,850.00
Packaging Details: Wood cases in standard container or less than container load. Each set is wrapped in plywood case and transport in standard container.
Supply Ability: 100 Set/Sets per Quarter
Contact Now
All Products
Flake Ice Maker Machine (75)
Block Ice Maker Machine (63)
Ice Tube Maker Machine (13)
Slurry Ice Machine (18)
Artificial Snowfall Machine (15)
Evaporative Condenser Chiller (11)
Cooler Refrigeration Units (12)
Aluminum Refrigeration Row (5)
Solar Power Containerized Cold Room (11)
Cold Storage Refrigeration Units (2)
Detailed Product Description
Ice Shape: ICE BLOCK Ice Storage Capacity: Other
Applicable Industries: Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertis After Warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Local Service Location: Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Japan, Malaysia, Australia, Morocco, Kenya, Argentina, South Korea Showroom Location: None
Condition: New Voltage: 380V/220V
Power: 65kw/ton Dimension(L*W*H): Customized
Weight: 5000kg Warranty: 1 Year
After-sales Service Provided: Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Video Technical Support, Online Support Key Selling Points: Automatic
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Marketing Type: Hot Product 2019 Warranty Of Core Components: 1 Year
Core Components: Pressure Vessel, Motor, Other, Bearing, Gear, Pump, Gearbox, Engine, PLC Application: Fresh-keeping/seafood Preservation
Cooling Way: Water/Air Cooling Refrigerant: R22/R404A
Material: Stainless Steel 304 Ice Size: 5~50kg
Compressor: Bitzer/Bock Control System: Siemens PCL Program Control System
Expansion Valve: Denmark Brand Danfoss Product Name: Direct System Block Ice Machine
Keyword: Block Ice Machine Port: Shanghai

Product Description



Direct System Block Ice Machine BYB

The direct block ice machine adopts a food-grade aluminum alloy plate as evaporator material, only though a water feeding valve, the water is filled into the ice cans automatically, no chemical residues during the ice-making process. Block ice is kept far away from any pollution, especially produce quality ice block, which is sanitary and suitable for eating purpose and cooling purposes.This direct block ice maker produces blocks in a few hours, which means that the space requirements are reduced considerably.

Block Ice Making Machine for Fresh-keeping from China Manufacture 0


Working principle:
Yixing ICS direct system block ice machine adopts edge-leading refrigeration industry technology.

1. After direct heat exchange between refrigerant and water, in 5 to 8 hours, water is frozen out into ice.

2. By that time, PLC controls the machine automatically into ice doffing process.

3. Direct system utilizes hot Freon to defrost ice; so the defrosting process is fast.




Model
Daily capacity
Refrigerant
Electricity consumption
Install power
Operating weight
Size(L*W*H)
BYB
1-30 TON
R22/R404A
65KW/TON
2.5-150 KW
10TON
customized



Main Features

1) The evaporator adopts a special aluminum alloy plate which is more durable and meets food hygiene requirements.

2) Ice thawing and ice doffing are automatic therefore no manual work is needed, 1 person is enough.

3) The ice is doffed by batch and the whole ice doffing process only takes 25 minutes.

4) The whole batch ice blocks can be moved by forklift, or designed with ice moving out a device, quick and convenient.


 Block Ice Making Machine for Fresh-keeping from China Manufacture 1


Block Ice Application

a.Ice factory

b.Fresh preservation

c.Ice engraving;

d.Edible ice


Block Ice Making Machine for Fresh-keeping from China Manufacture 2

  • Aluminum evaporator adopts special technique to make sure the ice conforms to food grade standards
  • In other words, the ice can be directly consumed
  • Besides saving labor work and electricity consumption, its unique modular design saves much floor area than traditional brine system block ice machine

Detailed Images


Forklift  Ice Moving Device

Original "mobile ice holding plate design", shovel whole ice holding plate out with forklift, each process takes abut 3 minutes, saving 90% labor and time to a great extend, highest deree of automation.

Block Ice Making Machine for Fresh-keeping from China Manufacture 3



HYDRAULIC SYSTEM+WIRE ROPE HOISTING
Advantages of hydraulic system:
Save more space
Lower noise
Long service life
Small friction
Good balance
Block Ice Making Machine for Fresh-keeping from China Manufacture 4

Automatic characters

Add water automatically
Make ice automatically
Doff ice automatically
Move ice automatically
                                                                     Block Ice Making Machine for Fresh-keeping from China Manufacture 5


Below is the main specification of this 10-ton daily direct system block ice machine:



Power supply: 380V/3P/50Hz (Customized

Refrigerant: R404A/R22

Weight of each block ice: 50kg/25kg (customized)

Cooling mode: Evaporative cooling

Ice doffing time: 25 minutes

 Need a person to operate: 1 person is enough,  Automatic

Compressor brand: Germany Bitzer

Solenoid Valve brand: Denmark Danfoss

Programmable logic controller: Germany

Siemens (tailor-made performance)

Electric parts brand: France Schneider


Packaging & Shipping



Block Ice Making Machine for Fresh-keeping from China Manufacture 6  Block Ice Making Machine for Fresh-keeping from China Manufacture 7

Block Ice Making Machine for Fresh-keeping from China Manufacture 8  Block Ice Making Machine for Fresh-keeping from China Manufacture 9





Our Services



Pre-Sales Service

* Inquiry and consulting support.
* Sample testing support.
* View our Factory.



After-Sales Service

* Training how to install the machine, training how to use the machine.
* Engineers available to service machinery overseas


Company Information



Yixing city Ice Source Refrigeration Equipment Limited is a comprehensive modern manufacture of all kinds of ice-making plants, cold room, high-efficiency cold air blower, energy-saving evaporative condenser, aluminum alloy pipe row, and various civil constructions, combined with cold room engineering.



ICS is located in Yixing, Wuxi, Jiangsu, CHINA. With over 20 year's successful experience in the Chinese market, we focus on technical innovation to improve the machine quality and strengthen innovation ability. By insisting on the spirit "unity, seeking the truth, pioneering and dedication", we commit ourselves to research and development of new technology, striving to create a comprehensive refrigeration enterprise in China.
