5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine

5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine

  • 5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine
  • 5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine
  • 5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine
  • 5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine
  • 5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine
  • 5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Yixing ICS
Certification: ce
Payment & Shipping Terms:
Minimum Order Quantity: 1 - 2 Sets
Price: $29,000.00
Packaging Details: Wood cases in standard container or less than container loadEach set is wrapped in plywood case and transport in standard container
Supply Ability: 10 Set/Sets per Month
Contact Now
All Products
Flake Ice Maker Machine (75)
Block Ice Maker Machine (63)
Ice Tube Maker Machine (13)
Slurry Ice Machine (18)
Artificial Snowfall Machine (15)
Evaporative Condenser Chiller (11)
Cooler Refrigeration Units (12)
Aluminum Refrigeration Row (5)
Solar Power Containerized Cold Room (11)
Cold Storage Refrigeration Units (2)
Detailed Product Description
Ice Shape: ICE BLOCK Ice Storage Capacity: None
Applicable Industries: Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, A After Warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Local Service Location: None Showroom Location: None
Condition: New Voltage: 220/380V
Power: 20.9kw Dimension(L*W*H): 6200*2000*2250mm
Weight: 4280kg Warranty: 1 Year
After-sales Service Provided: Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Video Technical Support, Online Support Key Selling Points: Automatic
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Marketing Type: New Product 2020 Warranty Of Core Components: 1 Year
Core Components: Pressure Vessel, Motor, Other, Bearing, Gear, Pump, Gearbox, Engine, PLC Product Name: Yixing ICS Block Ice Machine
Type: Automatic Block Ice Machine Material: Stainless Steel
Compressor: Bitzer Expansion Valve: Demark Danfoss
Refrigerant: R404a/R22a Cooling Way: Air Cooling/Evaporative Cooling
Application: Food Transportation, Seafood Preservation Ice Weight: 5-50kg
Freezing Time: 4-10 H Port: Shanghai
High Light:

20.9KW Block Ice Maker Machine

,

5T Block Ice Maker Machine

,

5000kg ice block machine

Commercial Ice Maker, 5T Daily Capacity Direct System Block Ice Machine For Sale

Product Description
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 0
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 1
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 2
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 3

Direct System Block Ice Machine

The direct refrigeration block ice machine adopts food-grade aluminum alloy plate as evaporator material, only though a water feeding valve, the water is filled into the ice cans automatically, no any chemical residues during ice making process. Block ice is kept far away from any pollution,
especially produce high quality ice block, which is sanitary and suitable for eating purpose and cooling purpose. This direct block ice maker produces blocks in a few hours, which means that the space requirements are reduced considerably.
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 4
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 5

Working principle

Yixing ICS direct system block ice machine adopts edge-leading refrigeration industry technology.
1. After direct heat exchange between refrigerant and water, in 5 to 8 hours, water is frozen out into ice.
2. By that time, PLC controls the machine automatically into ice doffing process.
3. Direct system utilizes hot Freon to defrost ice; so the defrosting process is fast.
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 6
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 7
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 8

Block Ice Application

a. Ice factory

b. Fresh preservation

c. Ice engraving

d. Edible ice
Aluminum evaporator adopts special technique to make sure the ice conforms to food grade standards. In other words, the ice can be directly consumed. Besides saving labor work and electricity consumption, its unique modular design saves much floor area than traditional brine system block ice machine.
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 9
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 10
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 11

Direct System Block Ice Machine Specification
Model
Daily capacity
Electricity consumption
Install power
operating weight
Dimension (L*W*H) mm
BYB-10D
1T
4.85kw
6kw
960kg
1800*1200*2000
BYB-30D
3T
11.52kw
14kw
2180kg
3600*1400*2200
BYB-50D
5T
20.9kw
25kw
4280kg
6200*2000*2250
BYB-100D
10T
33.98kw
50kw
8070kg
9800*2000*2410
BYB-150D
15T
59.15kw
75kw
11860kg
13500*2200*2565
Detailed Images
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 12
Main features
1) The evaporator adopts special aluminum alloy plate which is more durable and meets food hygiene requirements.
2) Ice thawing and ice doffing are fully automatic therefore no manual work is needed; 1 person is enough.
3) The ice is doffed by batch and the whole ice doffing process only takes 25 minutes.

4) The whole batch ice blocks can be moved by forklift, or designed with ice moving out device, quick and convenient.

Forklift Ice Moving Device

Original "mobile ice holding plate design", shovel whole ice holding plate out with forklift, each process takes about 3 minutes,
saving 90% labor and time to a great extent, highest degree of automation.
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 13
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 14

Hydraulic System+Wire Rope Hoisting
Advantages of hydraulic system:

*Save more space
*Lower noise
*Long service life
*Small friction
*Good balance

Automatic characters
*Add water automatically

*Make ice automatically

*Doff ice automatically

*Move ice automatically
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 15
Related Products

Certificate
CE
M.2019.206.C0141
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 16
Packing&Shipping

Standard export packing

Wood cases in standard container or less than container load
Each set is wrapped in plywood case and transport in standard container
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 17
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 18
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 19
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 20
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 21
Our Services

Pre-Sales Service

* Inquiry and consulting support.
* Sample testing support.
* View our Factory.

After-Sales Service

* Training how to install the machine, training how to use the machine.
* Engineers available to service machinery overseas
Company Introduction
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 22
Yixing city Ice Source Refrigeration Equipment Limited is a comprehensive modern manufacture of all kinds ice making plants, cold-room, high-efficiency cold air blower, energy-saving evaporative condenser, aluminum alloy pipe row and various civil constructions, combined with cold room engineering.

ICS is located in Yixing, Wuxi, Jiangsu, CHINA. With over 20 year's successful experience in Chinese market, we focus on the technical innovation to improve the machine quality and strengthen innovation ability. By insisting on the spirit "unity, seeking truth, pioneering and dedication", we commit ourselves to research and development of new technology, striving to create a comprehensive refrigeration enterprise in China
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 23
5T 6200x2000x2250mm 20.9KW Block Ice Maker Machine 24
