SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day

SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day

  • SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day
  • SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day
SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Yixing ICS
Certification: ce
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set/Sets
Price: $5,000.00 - $100,000.00 / Set
Supply Ability: 50 Set/Sets per Quarter
Contact Now
All Products
Flake Ice Maker Machine (75)
Block Ice Maker Machine (63)
Ice Tube Maker Machine (13)
Slurry Ice Machine (18)
Artificial Snowfall Machine (15)
Evaporative Condenser Chiller (11)
Cooler Refrigeration Units (12)
Aluminum Refrigeration Row (5)
Solar Power Containerized Cold Room (11)
Cold Storage Refrigeration Units (2)
Detailed Product Description
Ice Shape: Flake Ice Condition: New
Voltage: 220~380V Power: 70kw
Dimension(L*W*H): Customize Weight: Depends
Warranty: 1 Year After-sales Service Provided: Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Video Technical Support, Online Support
Capacity: 10 Ton Name: Flake Ice Making Machine
Compressor: Bitzer Cooling Way: Evaporative Cooling
Application: Fresh-keeping/fishery Material: SUS304 Staineless Steel
Refrigerant: R404a/R22 Expansion Valve: Danfoss Brand
Control System: PLC+Touch Screen Solenoid Valve: Saginomiya (Japan)
Type: Automatic Flake Ice Machine
High Light:

Big Ice Making Machine 30ton/day

,

SUS304 Big Ice Making Machine

,

ice flake maker machine 30ton/day

Name
Big industrial ice making machines
Compressor
Hanbell/Bitzer
Refrigeration parts
Danfoss
Water supply
fresh water
Cooling way
water cooling
Refrigerants
R22/R404a
Application
Concrete cooling etc.
Ice Thickness
1.5~2.2mm

SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day 0

Flake ice is a kind of irregular ice with size about 40*40 mm and thickness around 1-2 mm.


The thin ice can be directly used for stirring and mixing refrigerated materials.

Besides, flake ice has no acute edges and corners so it will not damage the surface of cooled object.

With large contact area and fast cooling speed, flake ice can realize high efficiency cooling effects.

SPECIFICATIONS FOR 1 TON FLAKE ICE MACHINE
MODEL
DAILY CAPACITY
REFRIGERANT
OPERATING POWER
OPERATING WEIGHT
BYF-10AS
1 TON
R404A
5KW
200KG
SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day 1

Main Features

1) Internally-scraping ice skate can help reduce energy consumption and prevent leakage of refrigerant.

2) stainless steel materials, advanced processing equipment and heat treatment processing ensure the best heat transfer efficiency.

3) The design of large water receiving plate can prevent water leaking at the bottom of evaporator

4) Direct liquid feeding and dry evaporation, simple&safe to control.

5) Integrated modular design, convenient to install and maintain.

SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day 3
Detailed Images
SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day 5
SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day 7



Flake ice is easy to crush and mold, with almost zero damage to the cooled products.

The internal structure of the evaporator is specially designed to improve the heat-exchange efficiency and to keep the loop unblocked with special processing technology.



SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day 9







The internally scraping ice making mode has been adopted, which reduces the loss of energy and avoids the leakage of refrigerant.

SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day 11
Certifications

CE Certificate Number:

M.2019.206.C0141

SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day 13
Related Products
SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day 15
SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day 17
SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day 19

Slurry Ice Machine

96% Response Rate

Flake Ice Machine

94.8% Response Rate

Cold Room

98% Response Rate

Our Service
SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day 21

Pre-Sales Service

* Inquiry and consulting support.
* Sample testing support.
* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.

Packing & Delivery
SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day 23
SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day 25
Activities
SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day 27
SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day 29
About Yixing ICS

Yixing city Ice Source Refrigeration Equipment Limited is a comprehensive mordern manufacture of all kinds ice making plants, cold room, high-efficiency cold air blower, energy-saving evaporative condenser, aluminum alloy pipe row and various civil constructions, combined with cold room engineering.



ICS is located in Yixing, Wuxi, Jiangsu, CHINA. With over 20 year's successful experience in Chinese market, we focus on the technical innovation to improve the machine quality and strengthen innovation ability. By insisting on the spirit "unity, seeking truth, pioneering and dedication", we commit ourselves to research and development of new technology, striving to create a comprehensive refrigeration enterprise in China.

SUS304 Big Ice Making Machine Concrete Cooling Equipment 30ton/Day 31
